Popis
| Output: | 200 W into 8 ohms 350 W into 4 ohms 550 W into 2 ohms 750 W into 1 ohm |
| Filtering capacity: | 82,000 µF |
| Frequency Response: | 0 – 300,000 Hz (-3 dB) |
| Damping Factor: | > 1,800 @ 10 kHz > 10,000 @ 100 Hz |
| Harmonic Spectrum: | k2 typ. -117 dB for 25 Watts @ 4 ohms k3 typ. -140 dB for 25 Watts @ 4 ohms |
| Intermodulation | < -110 dB SMPTE 100 Hz : 20 kHz, 4 : 1, 50 W @ 4 ohms |
| THD + N: | < -105 dB at 1 kHz, 35 Watts @ 2 ohms between 20 Hz and 20 kHz |
| SNR: | > 122 dB |
| Input Impedance: | RCA: 37 kOhm, 220 pF XLR: 3 kOhm, 170 pF |
| Power Consumption: | max. 1,000 W |
| Mains connection: | 120 or 230 V, 50…60 Hz |
| Dimensions: | width 215 mm height 190 mm depth 500 mm |
| Weight: | 22 kg/mono block |
