Popis
| Output: | 2 x 200 Watts into 8 ohms 2 x 300 Watts into 4 ohms 2 x 450 Watts into 2 ohms 1 x 600 Watts into 8 ohms (bridged) 1 x 900 Watts into 4 ohms (bridged) |
| Filtering capacity: | 188,000 µF |
| Frequency Response: | 0 – 300,000 Hz (-3 dB) |
| Damping Factor: | > 10,000 @ 100 Hz |
| Harmonic Spectrum: | k2 typ. -120 dB for 25 Watts @ 4 ohms k3 typ. -123 dB for 25 Watts @ 4 ohms |
| Intermodulation: | < -110 dB SMPTE 100 Hz : 20 kHz, 4 : 1, 50 W @ 4 ohms |
| Channel Separation: | > 100 dB @ 1 kHz |
| THD + N: | < -102 dB at 1 kHz, 35 Watts @ 2 ohms between 20 Hz and 20 kHz |
| SNR: | > 106 dB at 10 Veff |
| Input Impedance: | 37 kOhm, 220 pF |
| Power Consumption: | max. 1,500 W |
| Mains connection: | 120 or 230 V, 50…60 Hz |
| Dimensions: | width 430 mm height 175 mm depth 315 mm |
| Weight: | 28 kg |
