Popis
STYLUS TYPE | Nude Shibata on Boron cantilever |
---|---|
WEIGHT | 12,5g |
FREQUENCY RESPONSE | 20 – 30.000 Hz (-3dB) |
OUTPUT VOLTAGE | 0,3 mV |
CHANNEL SEPARATION | > 25 dB (1kHz), > 17 dB (15kHz) |
COMPLIANCE DYNAMIC/LATERAL | 15 μm/mN |
TRACKING FORCE RANGE | 2,0-2,5 g (20-25 mN) |
RECOMMENDED TRACKING FORCE | 2,3g (23mN) |
TRACKING ANGLE | 20° |
COIL WIRE MATERIAL | 8-Nines copper |
INTERNAL IMPEDANCE, DC RESISTANCE | 5 Ohm |
RECOMMENDED LOAD RESISTANCE | > 15 Ohm |
