Popis
Main Bearing Spindle Grade 303 Stainless Steel
Main Bearing Ball Steel
Main Bearing Housing Brass
Platter High Mass 10mm Glass Platter with Anodised Aluminium edge
Structure
Isolated Single plinth Design
Isolation
1-level decoupling
Motor
Vibration Isolated 24 Pole Synchronous
Pulley Solid Aluminium
Speed Controller
Built in High precision digitally Synthesised AC signal generator with high current low distortion output
Speed 33 RPM & 45 RPM (Switchable)
Dimensions (Including Lid (W x H x D)) 432 x 115 x 353 mm
Dimensions (Excluding Lid (W x H x D)) 432 x 104.5 x 353 mm
Weight 6.3 kg
Phono Stage
Built in MM phono stage
Phono Stage Bypass
Yes, with switch for external phono stage.
Phono Stage Gain (active) 42dB @ 1kHz
Phono Stage Signal to Noise (active) >64dB
Phono Stage Impedance (active) 47k / 100pF
Output
Stereo RCA with provided low capacitance phono cable
Power 5V 1.5A external SMPS
Tonearm Bearing Unipivot
Arm Material 5052 Aluminium top with ABS bottom section
Effective Length 240 mm
Effective Mass 14.9 g
Recommended Tracking Force 1.8 - 2.2 g
Internal Wiring 0.08OFC copper wire
