Popis
RX-V4A | RX-V6A | ||
---|---|---|---|
Verstärkersektion | Kanäle | 5.2 | 7.2 |
Rated Output Power (1kHz, 1ch driven) | 115 W (6 ohms, 0.9% THD) | 125 W (8 ohms, 0.9% THD) | |
Rated Output Power (20Hz-20kHz, 2ch driven) | 80 W (6 ohms, 0.06% THD) | 100 W (8 ohms, 0.06% THD) | |
Amplifier Section | Maximum Effective Output Power (1kHz, 1ch driven) | 145 W (6 ohms, 10% THD) | 150 W (8 ohms, 10% THD) |
High Slew Rate Amplifier | Yes | Yes | |
Surround Sound Processing | Surround:AI | N/A | N/A |
Dolby Atmos Height Virturalizer | N/A | Yes (via future update) | |
Dolby Surround | N/A | Yes | |
Surround Sound Ausstattung | CINEMA DSP | Yes | Yes |
DSP Programs | 17 | 17 | |
Dialog Level Adjustment | Yes | Yes | |
Virtual Presence Speaker | Yes | Yes | |
Virtual Surround Back Speaker | N/A | Yes | |
Dialogue Lift | N/A | Yes | |
SILENT CINEMA / Virtual CINEMA DSP | Yes | Yes | |
Dolby Atmos | N/A | Yes | |
Dolby TrueHD | Yes | Yes | |
Dolby Digital Plus | Yes | Yes | |
DTS:X | N/A | Yes | |
DTS-HD Master Audio | Yes | Yes | |
Audio Features | File Format | MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 192 kHz / 24-bit, WAV / AIFF: up to 192 kHz / 32-bit, DSD: up to 11.2 MHz | MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz |
DA Converter | 384 kHz / 32-bit BB PCM5101A | 384 kHz / 32-bit BB PCM5102A | |
Audio Ausstattung | Pure Direct | Yes | Yes |
Compressed Music Enhancer | Yes | Yes | |
High-resolution Music Enhancer | N/A | N/A | |
YPAO multi-point measurement | N/A | Yes | |
YPAO Volume | N/A | Yes | |
Adaptive DRC (Dynamic Range Control) | Yes | Yes | |
Initial Volume & Maximum Volume Setting | Yes | Yes | |
A.R.T. Wedge | N/A | N/A | |
Bi-amp capability | Yes | Yes | |
Audio Delay | Yes (0-500 ms) | Yes (0-500 ms) | |
Video Features | HDMI eARC | Yes | Yes |
HDMI Pass-through | 8K60B, 4K120AB (via future update) | 8K60B, 4K120AB (via future update)*HDMI1-3 | |
HDMI Up-conversion | N/A | N/A | |
Dolby Vision | Yes | Yes | |
HDR 10+ | Yes (via future update) | Yes (via future update) | |
VRR/ALLM/QMS/QFT | Yes (via future update) | Yes (via future update) | |
Video Ausstattung | HDMI Audio Return Channel | Yes | Yes |
HDMI upscaling | Yes up to 4K | Yes up to 4K | |
Video adjustment | N/A | N/A | |
Connectivity | MusicCast Surround | Yes | Yes |
AirPlay 2 | Yes | Yes | |
XLR Terminal | N/A | N/A | |
Anschlüsse | HDMI Eingänge / Ausgänge | 4 / 1 | 7 / 1 |
HDMI CEC | Yes | Yes | |
USB Input | Yes | Yes | |
Network Port | Yes | Yes | |
Wi-Fi | Yes (2.4 / 5 GHz) | Yes (2.4 / 5 GHz) | |
Bluetooth | Yes (SBC / AAC) | Yes (SBC / AAC) | |
Front AV Input | USB | USB | |
Digital Audio Input/Output: Optical | 1 / 0 | 1 / 0 | |
Digital Audio Input/Output: Coaxial | 1 / 0 | 1 / 0 | |
Analog Audio Input/Output | 3 / 0 | 4 / 0 | |
Phono Eingang | N/A | Yes | |
Component Video Input/Output | N/A | N/A | |
Composite Video Input/Output | N/A | N/A | |
Preout | 0.2-ch | 2.2-ch | |
Headphone Output | 1 | 1 | |
Radiosektion | FM / AM Radio | Yes (Availability varies by region.) | Yes (Availability varies by region.) |
DAB Radio | Yes (Availability varies by region.) | Yes (Availability varies by region.) | |
Bedienung | On-screen display | Graphical User Interface | Graphical User Interface |
SCENE | Yes (4 sets) | Yes (8 sets) | |
App Control | Yes (iPhone / iPad / Android phone / tablet) | Yes (iPhone / iPad / Android phone / tablet) | |
Web Browser Control | N/A | Yes | |
Fernbedienung | Yes | Yes | |
Multiroom Ausstattung | Zone 2 Audio Ausgang | N/A | Preout |
Zone 3 Audio Ausgang | N/A | N/A | |
Zone 4 Audio Ausgang | N/A | N/A | |
Powered Zone | N/A | Zone 2 | |
Zone Video Output | N/A | N/A | |
Zone B Output | N/A | N/A | |
Zone GUI | N/A | N/A | |
RS-232C Schnitstelle | N/A | N/A | |
+12V Trigger Ausgänge | N/A | 1 | |
Fernsteuereingänge | N/A | N/A | |
Party Mode | N/A | Yes | |
Basics | Standby Power Consumption (IR only) | 0.1 W | 0.1 W |
Auto Power Standby | Yes | Yes | |
ECO mode | Yes | Yes | |
Abmessungen ( B x H x T ) | 435 W x 171H x 377D mm (with antenna up:435 W x 245 H x 377 D mm) | 435 W x 171 H x 377 D mm (with antenna up:435W x 245H x 377D mm) | |
Gewicht | 8.8 kg | 9.8 |
